S804100
Publish time 2025-04-22 15:49
Commercial Defrost Controls
| Voltage: | 120 |
| Switching: | 1 NO/ 2 NC |
| Time initiated/Time terminated: | Yes |
| Time initiated temperature: | No |
| Pressure terminated: | No |
| Amperage: | 40-amp non-inductive @ 120, 208 or 240 VAC |
| Maximum hp:: | 2 hp @ 120, 208 or 240 VAC |
| Pilot Duty: | 690 VA @ 120, 208, or 240 VAC |
| Operating temperate range: | -22 °F to 104 °F (-30°C to 40°C) |
| Overall case dimensions: | 7.697"H x 4.4"W x 3.8" D |
